Engine oil

Engine oil, capacity max 1.1 gal (max 4 l), with filter replacement

Specification SAE 5W-40, API SL/JASO MA2, Additives (for in-

stance, molybdenum-based substances) are pro-

hibited, because they would attack the coatings

on engine components, BMW Motorrad recom-

mends BMW Motorrad ADVANTEC Ultimate oil.

Engine oil, quantity for topping up max 0.8 quarts (max 0.8 l), Difference between

MIN and MAX

BMW recommends

Engine

Engine number location Lower right of engine block beneath the starter

Engine type A74B12M

Engine design Air-cooled/liquid-cooled two-cylinder four-stroke

opposed-twin engine with two overhead, spur-

gear-driven camshafts, a counterbalance shaft,

and variable intake camshaft control BMW Shift-

Cam

Displacement 1254 cc (1254 cm

)

Cylinder bore 4 in (102.5 mm)

216

Technical data

Questions and Answers:

Need help?

Do you have a question about the BMW R 1250GS Adventure and is the answer not in the manual?

BMW R 1250GS Adventure Specifications

General

Displacement	1, 254 cc
Front Suspension	BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut
Tire, Front	120/70 R19
Tire, Rear	170/60 R17
Bore x Stroke	102.5 mm x 76 mm
Compression Ratio	12.5:1
Fuel System	Electronic fuel injection
Max Power	136 hp at 7, 750 rpm
Max Torque	143 Nm at 6, 250 rpm
Transmission	6-speed
Fuel Capacity	30 liters
Seat Height	890 / 910 mm (adjustable)
Curb Weight	268 kg
Rear Suspension	BMW Motorrad Paralever; cast aluminum single-sided swing arm with WAD strut (weight-related damping)
Fuel consumption	4.75 l/100 km
Fuel type	Premium unleaded
Front Brake	Dual 305 mm discs, 4-piston calipers
Rear Brake	Single disc brake, diameter 276 mm, 2-piston floating caliper
ABS	BMW Motorrad Integral ABS
Length	2, 270 mm
Width	980 mm
Dry Weight	249 kg (549 lbs)
Clutch	Wet clutch with anti-hopping function, hydraulically actuated
Frame	Two-section frame
Engine Type	Air/liquid-cooled flat twin (Boxer)
