BMW S 1000XR 2018 User Manual

Icon for heating stages is hid-
den.
The heating is deactivated.
Seat
Removing seat
Park motorcycle, ensuring that
support surface is firm and
level.
Push down on rear part of
seat 2 to relieve the strain on
the lock and at the same time
unlock the seat lock with vehi-
cle key 1 counterclockwise.
Lift seat at rear and remove.
Lay the seat on a clean sur-
face.
Install seat
Position the seat with
mounts 1 in buffers 2 on left
and right.
Lower the rear of the seat and
engage the seat in the latching
mechanism.
4
62
z Operation

BMW S 1000XR 2018 Specifications

General

Displacement	999 cc
Transmission	6-speed
Tires Front	120/70 ZR 17
Tires Rear	190/55 ZR 17
Engine Type	Liquid-cooled 4-stroke in-line four-cylinder engine
Max Power	165 hp at 11, 000 rpm
Max Torque	114 Nm at 9, 250 rpm
Front Suspension	Upside-down telescopic fork, 46 mm diameter
Rear Suspension	Aluminum 2-sided swing arm, adjustable rebound damping
Front Brakes	Twin disc, 320 mm, 4-piston radial calipers
Rear Brakes	Single 265 mm disc, single-piston caliper
ABS	BMW Motorrad ABS
Fuel Capacity	20 liters
Seat Height	840 mm
Weight	228 kg
Length	2, 183 mm
Width	940 mm
Height	1, 408 mm
Frame	Aluminum bridge type
