4.5 Install the BMW Wallbox
1. The product is a stationary, wall-mounted
device. It contains a mounting template to mark
the screw positions for the mounting bracket
and the optional cable holder.
2. Secure the mounting bracket to the wall.
We recommend the following screw types:
- Masonry walls:
Countersunk screws 1/4". Tightening torque:
8.8 Nm (78 lb in)
- Drywalls supported by wooden posts:
Wood screws No. 8, at least 2” in length.
Tightening torque:
3 Nm (26 lb in)
3. Align the screw holes using the mounting
bracket and product.
4. Install and secure the product on the
mounting bracket using the Torx T30 screws
supplied.
Tightening torque: 1.5 Nm (13 lb in)
14
