BMW Wallbox User Manual

36 pages

To Next Page

To Previous Page

Part number 61 90 5 A1E

1B1

61 90 5 A1E

1B2

61 90 5 A1E

1B3

61 90 5 A1E

1B4

61 90 5 A1E

1B5

Internal fault

current detection

Alternating

current:

15~30 mA

Direct current:

3~6 mA

Alternating

current:

15~30 mA

Direct current:

3~6 mA

Alternating

current:

20 mA

Alternating

current:

15~30 mA

Direct current:

3~6 mA

Alternating

current:

20 mA

Protection against

electric shock

Class II

Housing ingress

protection

(for indoors and

outdoors)

IP65 IP65 NEMA 3S IP65 IP65

Dimensions

(W x H x D)

270x370x185 mm

Weight 6 kg 6 kg 8 kg 6 kg 6 kg

Electrical

protection from

Overcurrent, short-circuit, overvoltage,

undervoltage, earth faults, excess temperature.

Questions and Answers:

S
Sean JohnsJul 29, 2025
How to troubleshoot a BMW Wallbox LED display with no power?
- J
  Jennifer ClarkJul 29, 2025
  If the LED display of your BMW Automobile Accessories has no power supply, check the RCCB and circuit breaker and switch them on if necessary. If this doesn't resolve the issue, contact your local dealer.

BMW Wallbox Specifications

General

Charging Power	Up to 22 kW
Connector Type	Type 2
Protection Rating	IP54
Connectivity	Wi-Fi, Ethernet
Compatibility	All electric and plug-in hybrid vehicles
Voltage	230 V / 400 V (3-phase)
Amperage	Up to 32 A
Mounting	Wall-mounted
