Engine Oil
Bobcat 2200 Gasoline and Diesel Vehicle Operation & Maintenance Manual Page 37
7. Use a socket- or box-end (do not use an open-end) wrench to replace the oil drain plug. Turn the plug
clockwise and tighten to 29 ft-lb (40 N·m) for gasoline vehicles, 31 ft-lb (42 N·m) for diesel vehicles.
Engine Oil Filter Change
1. Drain the engine oil. See Engine Oil Draining on page 36.
2. Place the oil drain pan under the engine oil filter (2) (Figure 22 or Figure 23).
3. Remove the engine oil filter. Turn it counterclockwise and drain the residual oil in the filter port and filter
into the oil drain pan. See following NOTE.
Figure 21 Engine Oil Drain Plug and Pan – Gasoline
Vehicles
Figure 22 Replace Engine Oil Filter – Gasoline
Vehicles
Figure 23 Engine Oil Drain Plug and Oil Filter – Diesel
Vehicles
1
2
1
2
VIEW FROM UNDERSIDE OF VEHICLE
