2.3 Electrical data
ESDP12 ESDP30
Electrical supply See Table 1 See Tables 2 and 3
Full load current ratings See Table 1 See Tables 2 and 3
Motor type 0.4 kW, 1-phase,
squirrel cage induction motor,
TEFC, 4-pole, B class insulation
capacitor run.
Electrical supply voltage
100 115 200 230
Full load current rating: A
50 Hz 4.2 - 2.0 2.2
60 Hz 4.3 3.8 2.2 1.9
Motor rotational speed: r.min
-1
50 Hz 1430 - 1420 1440
60 Hz 1720 1740 1710 1730
Table 1 - ESDP12 pump full load current ratings and motor speed
Electrical supply voltage
200 208 230 380 415 460
Full load current rating: A
50 Hz 2.7 - - 1.57 1.63 -
60 Hz 2.6 2.5 2.5 - - 1.47
Motor rotational speed: r.min
-1
50 Hz 1460 - - 1470 1470 -
60 Hz 1740 1750 1760 - - 1770
Table 2 - ESDP30 pump full load current ratings and motor speed: 3-phase pumps
Electrical supply voltage
100 115 200 230
Full load current rating: A
50 Hz 8.5 - 4.3 3.9
60 Hz 7.7 6.7 3.9 3.4
Motor rotational speed: r.min
-1
50 Hz 1430 - 1430 1450
60 Hz 1720 1740 1720 1740
Table 3 - ESDP30 pump full load current ratings and motor speed: 1-phase pumps
10 ESDP12 and ESDP30 Scroll Pumps
