BLT421 Product Manual
2
1.2 Technical parameters
Cutting head
BLT421
Laser wavelength:
1030-1090nm
Laser power:
≤8kW
Fiber interface:
QBH, EOC
Spot magnification:
M=1.5/2.0 (100:150/100:200)
Focus adjustment range:
±50mm (optical ratio 1:2 100:200)
NA:
Max.0.13 at Fc100
Centering adjustment range:
±1.5mm
Focus acceleration:
7.5m/s²
Cutting gas interface:
ø10, maximum 25bar (2.5Mpa)
Nozzle cooling gas connection:
ø6, maximum 5bar (0.5Mpa)
Water cooling interface:
ø8, maximum 5bar (0.5Mpa), minimum flow 2.0l/min
Operating temperature:
5～55℃
storage temperature:
-25～+55 ℃
size:
404x122
weight:
About 5.5kg
Notice:
To avoid damage to the cutting head during storage and transportation, pay attention to
the following:

The cutting head should be stored within the allowable temperature and humidity
range.
 Avoid storage in and near magnetic fields such as permanent magnets or strong
alternating fields.

Avoid collision of the cutting head.
