Description
All dimensions in mm.
* Depending on the length of the lying surface
The single post at the head and leg end is optional.
The dimension in brackets is optional
Item numbers
Designation item no.
Continuous wood / steel side rail
Two-part (Fig. 1)
Wood side rail (set: 95 / 95mm)
90223
Wood side rail (set: 95 / 110mm)
91247
Legend
Steel side rail (set: 95 / 110mm
91314
Area Description
Three-part (Fig. 2)
A Distance between the head part and the side rail
B Height 1 of side rail
Wood side rail (set: 95 / 95mm)
91566
Wood side rail (set: 95 / 110mm)
91531
C Height 2 of side rail
D Width 1 of the side rail
E Distance between the elements within the
Side rail
F Distance between the divided side rails
G Distance between the lying surface and the
upper edge of the side rail
H Height of the top edge of the side rail above the
mattress without compression
I Thickness of the mattress for the intended
use
J Width 2 of the side rail
K Smallest dimension between side rail and
lying surface (or the panel, if any)
L Distance between the foot part and the side rail
