60 M10 x 20 Washer (28)
97 M12 x 20 Washer (1)
61 M8 x 24 Washer (4)
101 M10 x 30 Washer (4)
62 M8 Spring Lock Washer (4)
71 M12 Jam Nut (1) 70 M10 Nylon Lock Nut (34)
EXM1 Hardware Diagram
( Shown in actual size )
