STEP
1A
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. Do Not wrench tighten
until end of
1. Attach Stabilizing Leg P to the Lower Main Frame A as shown using:
(1) 98 m10 x 110 hex head bolt
(2) 101 m10 x 30 washer
(1) 4 4 ¼” pulley (This goes inside Lower Main Frame A)
(2) 94 Pulley Spacers
(1) 70 m10 nylon lock nut
NOTE:
The Pulley (4) ts inside Lower Main Frame (A). Leave this Pulley nger tight, you
will be installing a cable in
2. Attach two Foot Caps 46 to Stabilizing Leg P as shown.
3. Attach Lower Main Frame A to Rear Leg B and Rear Upright C using:
(2) 55 m10 x 65 hex head bolt
(2) 70 m10 nylon lock nut
4. Attach two Foot Caps 46 to Rear Leg B as shown.
