Body Solid EXM1 - Assembly Step 1 B; Attach Upper Main Frame D to Lower Main Frame A; Attach Flat Plate H; Attach Bracket AB to Upper Main Frame D and Rear Upright C

20
STEP
1B
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. Do Not wrench tighten
until end of
1. Attach Upper Main Frame D to Lower Main Frame A as shown using:
(2) 58 m10 x 105 hex head bolt
(4) 60 m10 x 60 washer
(2) 70 m10 nylon lock nut
2. Attach Flat Plate H as shown using:
(2) 55 m10 x 65 hex head bolt
(4) 60 m10 x 60 washer
(2) 70 m10 nylon lock nut
3. Attach Bracket AB to Upper Main Frame D and Rear Upright C as shown using:
(2) 55 m10 x 65 hex head bolt
(2) 70 m10 nylon lock nut
4. Attach one End Cap 17 to Upper Main Frame D as shown.
STEP
3
