Body Solid EXM1 - Assembly Step 2 B; Connect Top Plate 37 to Selector Rod 31; Slide Top Plate 37 and Selector Rod 31 onto Guide Rods G; Insert Guide Rods G into Rear Upper Beam E

24
STEP
2B
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. Do Not wrench tighten until end of
At this point make sure that the gym is in the right location.
1. Connect Top Plate 37 to the Selector Rod 31 using:
(1) 35 m10 x 45 socket head allen bolt
(1) 64 m10 spring lock washer
Socket Head Allen Bolt 35 screws into the Selector Rod 31, in the top hole (it is threaded).
2. Slide Top Plate 37 and Selector Rod 31 onto Guide Rods G.
Slide two Shaft Collars 32 onto the two Guide Rods G as shown.
3. Insert Guide Rods G into Rear Upper Beam E and attach Upper Beam E to the Upper Main
Frame D and Rear Upright C using:
(2) 55 m10 x 65 hex head bolt
(2) 70 m10 nylon lock nut
Slide two Shaft Collars 32 up and into Rear Upper Beam E, and twist to lock.
You can wrench tighten the 2 pre-installed Socket Head Bolts 8 now.
4. Attach two End Caps 17 to Rear Upper Beam E as shown.
