26
STEP
3
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. Do Not wrench tighten until end of
1. Insert Plastic Bushing 93 into the Lower Main Frame A as shown.
Insert Front Foot Plate J into the Plastic Bushing 93 and into Lower Main Frame A as
shown and attach using:
(2) 52 m10 x 95 hex head bolt
(4) 60 m10 x 60 washer
(2) 70 m10 nylon lock nut
2. Attach End Cap 80 to the Front Foot Plate J as shown.
Attach End Cap 17 to the Lower Main Frame A as shown.
3. Attach Leg Extension Arm K to Lower Main Frame A by rst removing 3” shaft and then
attach as shown using:
(2) 57 m6 x 10 allen head bolt
(2) 61 m8 x 24 washer
NOTE:
Some of these parts are pre-installed
4. Attach two End Caps 17 to the top and bottom of Leg Extension Arm K as shown.
NOTE:
At this point you must make sure that the gym is level, stable and in the right location.
You should now wrench tighten all bolts and nuts on the mainframe unit only.
Do NOT wrench tighten the pulley bolt that holds Stabilizing Leg P to Lower Main
Frame A, as shown on page 19, later you will be installing a cable in Step 9.
STEP
3
