28
STEP
4A
Be careful to assemble all components
in the sequence they are presented.
1. Attach Back/Seat Pad AA to the Seat Pad Frame L as shown using:
(2) 56 m8 x 45 hex head bolt
(2) 62 m8 spring lock washer
(2) 61 m8 washer
Do NOT over-tighten these bolts. Tighten these bolts until spring lock washer is
at. Over-tightening these bolts will cause T-nuts in pads to strip out.
2. Slide two End Caps 23 into the front and back of Seat Pad Frame L as shown.
Slide End Cap 2 into the bottom of Seat Pad Frame L as shown.
3. Slide two Plastic Bushing 20 into the top and bottom of the opening in the Lower Main
Frame A as shown.
Insert Seat Pad Frame L into the two Plastic Bushings 20 in the opening in the Lower
Main Frame A as shown.
4. Hold the Seat Pad Frame L in place with the T-Shaped Pop Pin 21.
To stop the Seat Pad Frame L from sliding all the way out insert:
(1) 65 m6 x 10 socket head allen bolt
(1) 102 m6 spring lock washer
NOTE:
Some of these parts are pre-installed
