Body Solid EXM1 - Assembly Step 5 A; Attach Press Arm Pivot Q to Upper Main Frame D; Tighten Socket Head Bolts 8 in Upper Main Frame D; Install End Caps 1 into Press Arm Pivot Q

32
STEP
5A
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. Do Not wrench tighten until end of
1. Attach Press Arm Pivot Q to Upper Main Frame D as shown using Shaft 16 and:
(2) 99 m10 x 20 allen head bolt
(2) 101 m10 x 30 washer
2. Tighten the two Socket Head Bolts 8 in the top of Upper Main Frame D.
NOTE:
Some of these parts are pre-installed
3. Install two End Caps 1 into the top of Press Arm Pivot Q.
4. Check to make sure the Rubber Stop 19 and Jam Nut 47 are in Upper Main Frame D
as shown.
NOTE:
These parts are pre-installed
STEP
5B
