Body Solid EXM1 - Assembly Step 5 B; Install End Caps 7 into Press Arm R; Attach Press Arm R to Press Arm Pivot Q; Attach Handles S and T to Press Arm R

34
STEP
5B
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. Do Not wrench tighten until end of
1. Install two End Caps 7 into the top of Press Arm R.
2. Attach Press Arm R to Press Arm Pivot Q as shown using Shaft 5.
Install Round Pop Pin 13.
Tighten the two Socket Head Bolts 8 in Press Arm R.
NOTE:
Some of these parts are pre-installed
4. Attach Right Handle S and Left Handle T to Press Arm R as shown using for each handle:
(1) 51 m10 x 60 allen head bolt
(2) 60 m10 x 20 washer
(1) 70 m10 nylon lock nut
NOTE:
When installing the Handles the horizontal grip is pointed outward and the smaller grip
is pointed forward as shown.
NOTE:
You should now wrench tighten all bolts and nuts in step 5A and 5B. Do NOT re-tighten any
of the pad bolts. Leave all pulley bolts nger tight until after cable installation in Step 10.
STEP
5B
