Body Solid EXM1 - Cable Adjustment; Adjusting Chain on Short Cable 92

53
Cable Adjustment
First, remove the Weight Stack Pin 30 from the Weight Stack. This will release tension on the cables.
You can now remove the pulley inside the top of the Rear Upper Beam E and move the pulley up or down to
adjust the cable tension.
First, remove the Weight Stack Pin 30 from the Weight Stack. This will release tension on the cables.
You can now adjust the chain located at the top of Short Cable 92 and attached to Small Pulley Holder W.
Tension can be adjusted by selecting various links in this chain.
E
Rear Upper
Beam
W
Small Pulley
Holder
30
Weight Stack
Pin
