Body Solid EXM2500 - Assembly Instructions; Frame Assembly

18
STEP
1A
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. Do Not wrench tighten until end of
1. Attach (2) Weight Stack Shims d33, (2) End Caps d3, and (2) Frame Levelers d32
to the bottom of Main Base Frame A, as shown.
2. Attach (2) Foot Caps d2 to the ends of 2” x 2” Front Stabilizer E.
Attach 2” x 2” Front Stabilizer E With ONE BOLT to Main Base Frame A using:
(1) a3 1/2” x 3” hex head bolt
(1) c1 1/2” washer
(1) b1 1/2” nylon locking nut
Leave the one hole open for
3. Attach one Foot Cap d2 to the end of 2” x 2” Rear Stabilizer B.
Attach Main Base Frame A to 2” x 2” Rear Stabilizer B and 2” x 2” Upright C
as shown using:
(2) a3 1/2” x 3” hex head bolt
(2) b1 1/2” nylon locking nut
4. Attach 2” x 4” Upright D to Main Base Frame A using:
(2) a3 1/2” x 3” hex head bolt
(2) b1 1/2” nylon locking nut
5. Attach (1) Frame Leveler d32 to 2” x 2” Rear Stabilizer B.
Attach (2) End Caps d5 and apply the (2) Grip Tape pieces d15 onto Foot Brace K.
Slide Foot Brace K into 2” x 2” Rear Stabilizer B and attach as shown using:
(1) a6 3/8” x 2 1/2” hex head bolt
(2) c2 3/8” washer
(1) b2 3/8” nylon locking nut
STEP
2A
STEP
3B
