STEP
2B
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. Do Not wrench tighten until end of
1. Attach Leg Extension Seat Pad R to the Leg Ext. Seat Pad Frame I using:
(2) a11 5/16” x 2 3/4” hex head bolt
(2) c4 5/16” spring washer
(2) c3 5/16” washer
Do NOT over-tighten these bolts. Tighten these bolts until spring lock washer is
at. Over-tightening these bolts will cause T-nuts in pads to strip out.
2. Slide 60 x 45 Nylon Bushing d36 into the top of Leg Extension Main Frame F and
insert Leg Ext. Seat Pad Frame I into 60 x 45 Nylon Bushing d36.
3. Attach (2) Seated Row Foam Roller Bars AD onto 2” x 4” Upright D, as shown:
(1) a1 1/2” x 5” hex head bolt
(2) c5 1/2” round end cap washer
(1) b1 1/2” nylon locking nut
Then cover A1 and B1 with two 1/2” Bolt Cap d1
4. Slide (2) Foam Rollers d13 and (2) 1” Seated Row Foam Roller End Cap d39 onto
the (2) Seated Row Foam Roller Bars AD holding it in place as shown.
5. Attach Back Pad AC onto the 2” x 4” Upright D using:
(2) a10 5/16” x 5” hex head bolt
(2) c4 5/16” spring washer
(2) c3 5/16” washer
Do NOT over-tighten these bolts. Tighten these bolts until spring lock washer is
at. Over-tightening these bolts will cause T-nuts in pads to strip out.
STEP
3B
To Next Page
