STEP
3A
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. Do Not wrench tighten until end of
1. Attach Seated Press Arms P to the 2” x 4” Top Frame G using:
This hardware is pre-installed in Seated Press Arm P, loosen both allen head
bolts to remove shaft, install and then re-tighten. Pre-installed hardware shown in
diagram with a box around it.
(1)
2. Attach (2) 1” Small End Caps d38 onto the bottom handles on the Seated Press Arms P.
Attach (2) 1” Small End Caps d38 onto the side handles on the Seated Press Arms P.
3. Attach (2) 2” x 2” x 1.8” End Caps d3 onto the top of the Seated Press Arms P.
19 X 180L shaft
STEP
3B
