28
STEP
3B
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. Do Not wrench tighten until end of
At this point make sure that the gym is in the right location.
1. Insert (2) Guide Rods X into the Main Base Frame A.
Insert (2) 2 1/2” Rubber Donuts d10 onto the (2) Guide Rods X as shown.
Slide 20 Weight Stack Plates (one at a time) onto the (2) Guide Rods X. Make sure the
opening in each weight stack plate, for the Weight Stack Pin a13, is facing outward.
2. Attach Top Plate d29 to Selector Rod d19 using:
(1) a14 3/8” x 2” round bolt
(1) c6 3/8” spring washer
Slide Top Plate d29 and Selector Rod d19 onto Guide Rods X as shown.
3. Slide (2) Shaft Collars d35 onto the (2) Guide Rods X as shown.
Slide Weight Stack Top M onto the (2) Guide Rods X and attach Weight Stack
Top M to 2” x 4” Top Frame G using:
(2) a3 1/2” x 3” hex head bolt
(2) c1 1/2” washer
(2) b1 1/2” nylon locking nut
4. Attach (2) 2” x 2” x 1.8” End Caps d3 onto Weight Stack Top M.
Insert (2) Shaft Collars d35 into Weight Stack Top M, turn to attach, then tighten
allen bolt in the (2) Shaft Collars d35.
NOTE:
At this point you must make sure that the gym is level, stable and in the right location.
You should now wrench tighten all bolts and nuts on the mainframe unit only.
Do NOT re-tighten any of the pad bolts.
STEP
3B
