30
STEP
4A
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. Do Not wrench tighten until end of
1. Attach Right Pec Dec Arm N (there is a Red dot on this piece) onto the top of
2” x 2” Pec Dec Top L as shown using:
This hardware is pre-installed on 2” x 2” Pec Dec Top L and shown in diagram
with a box around it.
(1)
(1)
Attach (1) End Cap d3 onto Right Pec Dec Arm N as shown.
2. Attach Right Pec Dec Handle AB (there is a Red dot on this piece) onto the
Right Pec Dec Arm N using:
This hardware is pre-installed on Right Pec Dec Arm N and shown in diagram
with a box around it.
(1)
Right Pec Dec Handle AB has an arrow on it, the arrow should point up.
Attach (2) Small End Caps d38 onto Right Pec Dec Handle AB as shown.
3. Attach Left Pec Dec Arm O (there is a Green dot on this piece) onto the top of
Pec Dec Top L as shown using:
This hardware is pre-installed on Pec Dec Top L.
(1) 10mm x 16 hex head bolt
(1) 10mm washer
Attach (1) End Cap d3 onto Left Pec Dec Arm O as shown.
4. Attach 2” x 2” Left Pec Dec Handle AA (there is a Green dot on this piece) onto the
Left Pec Dec Arm O using:
This hardware is pre-installed on Left Pec Dec Arm O.
(1) 1/2” nylon lock nut
Left Pec Dec Handle AA has an arrow on it, the arrow should point up.
Attach (2) Small End Caps d38 onto Left Pec Dec Handle AA as shown.
NOTE: At this point you should now wrench tighten all bolts and nuts on this step.
M10 x 16mm hex head bolt
M10 washer
1/2” nylon lock nut
