STEP
4B
Be careful to assemble all components
in the sequence they are presented.
1. Attach (2) End Caps d3, and (1) End Cap d4 to the 2” x 2” Seat Pad Frame H as
shown. Attach Pec Dec Seat Pad S to the 2” x 2” Seat Pad Frame H using:
(2) a11 5/16” x 2 3/4” hex head bolt
(2) c4 5/16” spring washer
(2) c3 5/16” washer
You can wrench tighten these bolts now.
Do NOT over-tighten these bolts. Tighten these bolts until spring lock washer is
at. Over-tightening these bolts will cause T-nuts in pads to strip out.
2. Slide (2) Short Nylon Bushings d8 into the 2” x 2” Upright C and insert
2” x 2” Seat Pad Frame H into Short Nylon Bushings d8 as shown.
3. Attach Back Pad AC onto the 2” x 2” Upright C as shown using:
(2) a11 5/16” x 2 3/4” hex head bolt
(2) c4 5/16” spring washer
(2) c3 5/16” washer
You can wrench tighten these bolts now.
Do NOT over-tighten these bolts. Tighten these bolts until spring lock washer is
at. Over-tightening these bolts will cause T-nuts in pads to strip out.
