Body Solid EXM2500 - Page 34

34
STEP
5A
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. Do Not wrench tighten until the cables are
installed.
1. Insert (2) Pulleys d6 inside 2” x 4” Top Frame G, and attach using:
(2) a5 3/8” x 2 3/4” hex head bolt
(4) d12 steel bushing
(2) b2 3/8” nylon locking nut
2. Insert (2) Pulleys d6 into the (2) anges hanging off the bottom of 2” x 4” Top Frame G,
and attach using:
(2) a8 3/8” x 1 1/2” hex head bolt
(2) b2 3/8” nylon locking nut
3. Attach (2) Pulleys d6 onto the (2) anges hanging off the back of 2” x 4” Top Frame G,
and attach using:
(2) a7 3/8” x 1 3/4” hex head bolt
(2) d18 pulley cable guide
(2) c2 3/8” washer
(2) b2 3/8” nylon locking nut
4. Insert (1) (smaller) 3” Pulley d7 into 2” x 2” Upright C and attach using:
(1) a5 3/8” x 2 3/4” hex head bolt
(2) d12 steel bushing
(1) b2 3/8” nylon locking nut
