38
STEP
6
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. Do Not wrench tighten until the cables are
installed.
1. Insert (2) Pulleys d6 into Seated Press Arms P, and attach using:
(2) a4 3/8” x 7 1/4” hex head bolt
(4) c2 3/8” washer
(4) d21 5/8” steel bushing
(2) b2 3/8” nylon locking nut
2. Insert (1) Pulley d6 into the anges on the Weight Stack Top M as shown,
and attach using:
(1) a8 3/8” x 1 1/2” hex head bolt
(1) b2 3/8” nylon locking nut
To Next Page
