What to do if my Bodyguard Treadmill walking belt is slipping?
If your Bodyguard Treadmill walking belt is slipping, ensure that the walking belt is indeed slipping on both the front and rear rollers. If it is, you should tighten the walking belt. Refer to section 7.4 for instructions on how to do this.
What to do if my Bodyguard Treadmill drive belt is slipping?
If your Bodyguard Treadmill drive belt is slipping, first confirm that the drive belt is slipping on both the drive motor pulley and the front roller pulley. If it is, you should tighten the drive belt. See section 7.2 for instructions.
What to do if the Bodyguard T-30 display won't light up, but the motor control board lights are on?
If the display of your Bodyguard Treadmill does not light up when the power switch is turned on, but the lights on the Motor Control Board (MCB) are on, it could be due to loose data cable connectors, a damaged data cable, a damaged MCB, or a damaged display. First, ensure the data cable connectors are securely connected to both the MCB and the display. If the data cable is damaged, it will need to be replaced to allow power to pass from the MCB to the console. Data cables are often damaged when moving treadmills if they are not safely removed before lowering the upright masts.
What to do if my Bodyguard T-30 display won't light up and there are no lights on the motor control board?
If the display of your Bodyguard Treadmill does not light up when the power switch is turned on, and there are no lights on the Motor Control Board (MCB) under the motor cover, it indicates a power issue. Here's what you can check: * Ensure the wall socket is providing power by testing it with a multimeter or plugging in a lamp. * Inspect the power cord for any damage and test if it's passing 120 VAC of power. Replace if necessary. * Check if the power switch lights up when turned on; replace if needed. * Reset the circuit breaker by pushing it in. If it trips repeatedly, it might be damaged and need replacement. * Inspect all components and wiring before the MCB for 120 VAC to identify where the power is stopping. * Test if 120 VAC is entering the MCB using a multimeter.
What to do if the walking belt is not centered on my Bodyguard T-30?
If the walking belt on your Bodyguard Treadmill is not centered, first confirm that the treadmill is level and that the front and rear rollers are parallel. Then, adjust the rear feet to level the treadmill and complete the Walking Belt Alignment. See section 7.5 for detailed instructions.
Why does my Bodyguard T-30 say 'PLEASE PUT SAFETY KEY'?
If your T-45 or T-75 Bodyguard Treadmill displays 'PLEASE PUT SAFETY KEY', it means the safety key is either not in place or the safety switch inside the console is damaged or not connected. Ensure the safety key is correctly placed on the console. If the issue persists, remove the console's back metal plate and check that the safety switch wiring is connected to the upper board. Check for continuity; you may need to replace the safety switch or wiring.
How to fix a sticking walking belt on Bodyguard Treadmill?
To fix a sticking walking belt on your Bodyguard Treadmill, first perform a Current Test (see section 7.6.3) to check for high friction between the belt and deck. Then, perform Deck and Walking Belt Cleaning and Lubrication (see section 7.7). If cleaning and lubrication don't lower the amperage readings and solve the sticking, consider replacing the walking belt and rotating, flipping, or replacing the deck if they are worn. If amperage readings are within range but the problem continues, contact customer service.
What to do if the silicone keys on my Bodyguard T-30 Treadmill are not responding?
If the silicone keys on your Bodyguard Treadmill are not responding when pressed, it could be due to debris between the silicone keys and the Keypad PC Board, a damaged communication cable from the Keypad PCB, or a damaged Keypad PC Board. First, remove the PC board and carefully clean the sensors on the Keypad PC Board, as well as the underside of the silicone keys. If that doesn't work, replace the communication cable. If the Keypad PC Board is damaged and not transferring communication, it will need to be replaced.
What to do if the quick keys on my Bodyguard T-30 Treadmill membrane are not working?
If the quick keys on the membrane of your Bodyguard Treadmill are not working, it is likely due to a damaged Quick-Key Sensor Pad. The solution is to replace the Quick Key Sensor Pad.
On a Bodyguard T-30 Treadmill, what should I do if the JustGo key doesn't start the countdown, but the Contact HR function works?
If, on your Bodyguard T-30 Treadmill, the JustGo key doesn't initiate the 3,2,1 countdown but the Contact HR function works, the issue likely lies with the safety key or the safety switch. Ensure the safety key is correctly placed on the console. If the problem persists, remove the console's back metal plate and inspect the safety switch wiring connection to the upper board. Check for continuity; consider replacing the safety switch or wiring.
Details the product warranty and the process for registering your purchase for activation.
Explains the importance of proper grounding for electrical safety and warranty compliance.
Details how to use the safety key and emergency stop system for safe operation.
Explains how to use programs that adjust intensity based on target heart rate zones.
Guides users on creating, saving, and selecting custom workout programs.
Lists and explains common error codes displayed on the console for troubleshooting.
Explains AFDS warnings related to drive system friction and required maintenance.
Diagnoses and offers solutions for belt slipping, sticking, or centering problems.
General| Incline Range | 0 - 10% |
|---|---|
| Display | LCD |
| Programs | 12 |
| Motor Power | 2.0 HP |
| Running Area | 51 x 140 cm |
| Speed | 0.5 - 9 mph |
| Speed Range | 0.5 - 9 mph |
| Weight Capacity | 120 kg |
| Max User Weight | 120 kg |
| Dimensions (LxWxH) | 160 x 75 x 130 cm |
| Weight | 65 kg |
