B50 Tour Indoor Cycle
16
13
10
7
12
20
21
Step 2:
1. Slide the Vertical Seat Post (10) into the Seat Post Housing on the Main Frame (16). Then
slide the Seat Post (12) into the Vertical Seat Post (10), then Secure using a Flat Washer 1 (20)
and Locking Knob (21).You will have to slacken the knurled section of the Spring Adjustment
Knob (7) and pull the knob back and then select the desired height. Release the knob and
retighten the knurled portion.
2. Now x the Seat (13) to the Seat Post (12) as shown, and tighten the bolts around the
screws under the seat.
