Bodystat 1500MDD - Specifications

40
SPECIFICATIONS
MEASUREMENT:
Measuring Principle
Bioelectrical Impedance Analysis (BIA)
Lock-in Signal Conversion Technology
Impedance Measuring
Range
20 - 1300 Ω (ohms)
Accuracy
5 kHz Impedance
± 2 Ω (ohm)
50 kHz Impedance
± 2 Ω
50 kHz Resistance
± 2 Ω (ohm)
50 kHz Reactance
± 1 Ω (ohm)
50 kHz Phase Angle
± 0.2°
Resolution
± 1 Ω (both 5 and 50 kHz)
TEST CURRENT
620 Micro-Amps R.M.S.(Root Mean Square)
WAVEFORM
Sinusoidal
PC COMMUNICATION
Bluetooth Wireless Interface, USB
FREQUENCY
5 kHz & 50 kHz (KiloHertz)
INTERNAL POWER
SOURCE
Battery powered: 6 x AA (LR6)
Type: Alkaline
Battery preference: Duracell® model MN1500
Do not use type R6 Carbon zinc batteries.
DO NOT CONNECT AN EXTERNAL POWER SUPPLY
OPERATING
TEMPERATURE
+5
O
C to +40
O
C
STORAGE
TEMPERATURE
0
O
C to +60
O
C
HUMIDITY
Less than 70% R.H. (relative humidity)
up to +60
O
C - non-condensing
ATMOSPHERIC
PRESSURE
860 hPa to 1060 hPa
There are no serviceable components
