Power Output (RMS)
C35: 35W
C60: 60W
C100: 100W
Frequency Response
& Distortion
Transformer
†: 70 Hz to 16 kHz (± 2 dB) @ 1% max.
4-Ohm Direct Output: 20 Hz to 20 kHz (± 1 dB) @ 0.5% max.
Hum and Noise
MIC Input: 55 dB below rated output
AUX Input: 70 dB below rated output
TEL Input: 70 dB below rated output
Tone Control Action
Bass: +/- 11 dB @ 100 Hz
Treble: +/- 11 dB @ 10 kHz
Input Sensitivity
MIC Lo-Z Balanced: 600 μV
AUX: 85 mV
TEL: 75 mV
Outputs 8 ohms (C35 & C60 models only), 16 ohms, 25V, and 70V transformer-
isolated balanced or unbalanced; 4 ohms direct unbalanced
Output Connections: Speaker screw terminal strip, TAPE/BOOSTER RCA jack;
WMT1A RCA jack
Input Connections: (2) MIC Lo-Z screw terminals; (2) AUX Hi-Z RCA jacks,
TEL screw terminals
Controls: MIC1, MIC2/AUX1 (switch selected), AUX 2, BASS, TREBLE, TEL, VOX
Thermal Emissions (Full Power)
C35: 119.5 BTU/hr.
C60: 228.8 BTU/hr.
C100: 399.6 BTU/hr.
Power Requirements: 120V AC, 60 Hz
AC Line Draw
C35: 85W
C60: 148W
C100: 220W
Dimensions: 14
1
/2" W x 3
3
/4" H x 11" D (all models)
Product Weight
C35: 15 lb.
C60: 17 lb.
C100: 19 lb.
Approvals: Listed to UL Standard 60065 for U.S. and Canada
† Measured @ 2 dB below FRP
All specifications subject to change without notice.
8
Specifications
