(Fig. 7-3)
(Fig. 7-4)
7.2
Login Window Operational Notes
1. If you have a file called VoipSpeakersList.txt in the same folder where the application's jar
file is located, it will load the IP addresses contained in the file for selection in the login window.
The file is just a list of IP addresses, one per line. If the file does not exist, the application will
simply display the normal text field for the IP address to be entered manually.
2. Adding new IP addresses to the VoipSpeakersList.txt file.
You will notice a "+" button under the "IP Address" label. Pressing the "+" button
will open a dialog asking for IP Address input
(Figures 7-1 and 7-2)
.
Speaker Configuration Specific Options
8-21
Appendix
6. After Successful Login, the application’s
(Speaker Configuration, Figure 7-3; Quantum
Commander., Figure 7-4)
main window will be displayed.
3. If you have a speaker that you visit frequently, make it the first one in the list; then you can
press return after entering "password" and it will automatically select the first IP address from
the list and connect.
4. Sample VoipSpeakersList.txt file
(produces IP address list shown in the Speaker Configuration
Login in Figure 7-1
).
10.10.10.5
10.100.1.213
10.100.1.205
(Fig. 7-5)
The new IP address will be appended to the
VoipSpeakersList.txt file. If the file does not exist,
it will be created. That's all the "+" button does,
allow you to add more IP addresses to the list,
without having to directly edit the file.
To Next Page
