15
Make sure that the magnet attaches tightly to the work piece before turning on the motor unit
of the magnetic drilling machine. Our magnets have 2 coils; make sure that both coils are in
contact with the material. Do not connect any other machines to the electrical outlet the
magnetic drilling machine is plugged into, as it may result in the loss of magnetic force.
Always use the safety chain included. Drilling above your head is extremely dangerous and
is not recommended. For the use of magnetic drilling machines on pipes, not-flat or non-
magnetic materials, you may refer to vacuum tightening systems, pipe clamping systems and
machines with permanents magnets for steel tubes.
4.3 Switching motor on and off
The motor unit can only be switched ON when the magnet is activated. To switch the motor
ON, press the green button with marking “I”. To switch the motor OFF, press the red button
with marking “O”.
4.4 Tool lubrication
HORIZONTAL APPLICATIONS
In order to use the lubrication system, the tank must be filled with a cutting fluid or oil
1. Make sure the flow regulator is closed;
2. Unscrew the cap;
3. Fill the container with cutting fluid or oil;
4. Screw the cap back on.
• Adjust the fluid flow as required using the flow regulator;
• Add more cutting fluid if the shavings (metal chips) become blue.
VERTICAL APPLICATIONS
Dip the cutter in cutting paste or apply an appropriate spray.
WARNING: Do not use the lubrication system in vertical drilling applications. Instead
use cutting paste or spray
Make sure to use only suitable cutting oil or fluid. Proper lubrication will help you create
better and faster results, and extend the lifetime of your tools.
