S2000-2
Specifications
11
www.bolid.com
¾
Request-to-Exit Inputs
2
¾
Alarm Inputs
Wire Resistance
2 inputs to monitor intruder detectors’ conditions
(except for Swing-beam Barrier operation mode)
1 kOhm excluding termination resistance 8.2 kOhm
¾
Relay Outputs
Commuting Voltage
Commuting Current
Commuting Power
2 outputs to operate locking units or power relays
30VDC
7A
100W
¾
Tamper Switch
Yes
¾
Enclosure Protection
IP 20
¾
Operating Temperatures
−
30 to +50°
С
¾
Overall Dimensions
157
×
107
×
36 mm
¾
Weight
about 0.3 kg
¾
Average Lifetime
8 years
¾
Readiness Period
5 s max
10
12
Table of Contents
Default Chapter
3
Table of Contents
3
Features and Design
5
Specifications
9
Operating
13
Access Keys
14
Operation Modes
16
Two Entrance Doors Mode
16
One Entrance/Exit Door Mode
17
Turnstile Mode
18
Swing-Beam Barrier Mode
19
Two Sluice Doors Mode
20
Access Modes
22
Access Locked Mode
22
Access Locked by a Locking Key or Network Controller Command
22
Access Locked by Arming of Access Locking Alarm Loops
23
Free Pass Mode
23
Controlled Access Mode
24
Operating Principles
25
Access Granting
25
Alarm Loop Arming/Disarming
27
Alarm Loops
28
Two Factor Authentication
31
Access Rights
32
Passage Modes and Two or more Person Rule Access Control
32
Time Schedules
34
Anti-Passback Rules
35
Centralized Access Control and Alarm Loop Arming/Disarming
38
Key Pattern Based Access Control
40
Light and Sound Alarms
42
Data Communications Via RS-485 Interface
45
Condition Message Transmission
45
Remote Control Via RS-485 Interface
46
Installation
47
Standard Delivery
48
S2000-2 Mounting
48
S2000-2 PCB Layout
49
Wiring the S2000-2 for Two Entrance Doors Mode
50
Wiring the S2000-2 for One Entrance/Exit Door Mode
52
Wiring the S2000-2 for Turnstile Mode
54
Wiring the S2000-2 for Swing-Beam Barrier Mode
56
Wiring the S2000-2 for Two Sluice Doors Mode
59
Connecting Readers
61
Connecting Dallas Ibutton Readers
62
Connecting Readers with Touch Memory Output Interface
62
Connecting Readers with Wiegand Output Interface
63
Connecting Readers with ABA TRACK II Output Interface
63
Connecting an Arming Request Button
63
Connecting Door or Passage Sensors
64
Connecting Alarm Loops
66
S2000-2 Programming
67
System Configuration Parameters
68
Reader Configuration Parameters
70
Alarm Loop Configuration Parameters
75
Relay Configuration Parameters
75
Access Group Parameters
77
Access Key Configuration Parameters
80
Access Key Pattern Configuration Parameters
81
Key Programming
83
Programming the Controller Depending on Its Operation Mode
85
Two Entrance Doors Mode Programming
85
One Entrance/Exit Door Mode Programming
86
Turnstile Mode Programming
86
Swing-Beam Barrier Mode Programming
87
Two Sluice Doors Mode Programming
87
Maintenance
89
Technical Inspections
90
S2000-2 Operability Inspection
90
Self-Diagnostic Test
92
Condition Inspection of Readers' Connection Circuits
92
Condition Inspection of LOOP, DOOR and EXIT Circuits
93
Appendix Connecting some Models of Readers to the S2000-2 Controller
95
Bolid S2000-Proxy / S2000-Proxy N Reader Connection
96
Bolid Proxy-2A / Proxy-3A Reader Connection
96
PR-A03 / PR-A05 / PR-P09 Reader Connection
97
PR-H03 / PR-H05 / PR-M03 Reader Connection
97
Bolid Schityvatel-2 / Schityvatel-3 Reader Connection
98
