Menu Configuration
The menus of the camera are configured as described below. The initial settings of each item are in
bold.
SDI Menu Configuration
Menu EXPOSURE MODE FULL AUTO SLOW SHUTTER ON, OFF
S. SHUTTER LIMIT 1/1, 1/2, 1/4, 1/8, 1/15, 1/30
AE RESPONSE 1 - 48
GAIN LIMIT
10.7dB, 14.3dB, 17.8dB, 21.4dB, 25dB, 28.6dB, 32.1dB, 35.7dB,
39.3dB, 42.8dB, 46.4dB, 50dB
MANUAL GAIN 0, 2, 4, 6, 8, 10, 12, 14, 16, 18, 20, 22, 24, 26, 28 Db
GAIN LIMIT
10.7dB, 14.3dB, 17.8dB, 21.4dB, 25dB, 28.6dB, 32.1dB, 35.7dB,
39.3dB, 42.8dB, 46.4dB, 50dB
SPEED
1/1, 1/2,1/4, 1/8, 1/15, 1/30, 1/60, 1/90, 1/100, 1/125, 1/180,
1/250, 1/350, 1/500, 1/725, 1/1000, 1/1500, 1/2000, 1/3000,
1/4000, 1/6000, 1/10K sec
IRIS
CLOSE, F14, F11, F9.6, F8.0, F6.8, F5.6, F4.8, F4.0, F3.4, F2.8, F2.4,
F2.0, F1.6
HIGH SENSITIVITY OFF, ON
IRIS
IRIS PRI
IRIS
CLOSE, F14, F11, F9.6, F8.0, F6.8, F5.6, F4.8, F4.0, F3.4, F2.8, F2.4,
F2.0, F1.6
GAIN LIMIT
10.7dB, 14.3dB, 17.8dB, 21.4dB, 25dB, 28.6dB, 32.1dB, 35.7dB,
39.3dB, 42.8dB, 46.4dB, 50dB
SHUTTER PRI
SPEED
1/1, 1/2,1/4, 1/8, 1/15, 1/30, 1/60, 1/90, 1/100, 1/125, 1/180,
1/250, 1/350, 1/500, 1/725, 1/1000, 1/1500, 1/2000, 1/3000,
1/4000, 1/6000, 1/10K sec
GAIN LIMIT
10.7dB, 14.3dB, 17.8dB, 21.4dB, 25dB, 28.6dB, 32.1dB, 35.7dB,
39.3dB, 42.8dB, 46.4dB, 50dB
EX-COMP OFF , ON
WHITE BALANCE MODE AUTO
INDOOR
OUTDOOR
OPW
ATW
USER R GAIN 0-255
B GAIN 0-255
OUTDOOR AUTO
SVL AUTO
SVL
SVL OUTDOOR A.
PICTURE1 SHARPNESS 0-15
EFFECT OFF , B&W
NOISE REDUCTION OFF, 1-5
FLIP OFF, ON
MIRROR OFF, ON
DE-FLICKER OFF, ON
WDR OFF, ON
COLOR 1-15
HUE 1-15
CONTRAST 0-255
PICTURE2 CHROMA SUPRESS OFF, LOW, MID, HIGH
HLC MODE OFF , ON
BACKLIGHT COM. OFF , ON
STABILIZER OFF, ON
STABLE ZOOM OFF, ON
GAMMA 0, 1
