Technical Data
BOMAG
8
BW 900-2
Fig. 4
Dimensions in
mm
A B C D H H2 K K2 L O1/O2 W
BW 900-2
1143 956 458 560 1620 2340 200 372 2080 28 900
*
BW 900-2
Weights
Operating weight CECE kg 1326
Mean static linear load
CECE
kg/cm 7,4
Dimensions
Working width mm 900
Travel characteristics
Travel speed (1) km/h 0 to 4
Travel speed (2) km/h 0 to 7,5
Max. gradability without/
with vibration (soil de-
pendent)
% 40/30
