bon BEM-182 - External Remote Control

External Remote Control
Connecting GPI Port(RJ-45)
Turning the monitor off is recommended before cable connection. Assignable functions are listed
below.
Function Name Description
SDI-1 Input
Switches the input to SDI-1
SDI-2 Input
Switches the input to SDI-2
HDMI Input
Switches the input to HDMI
YPbPr Input
Switches the input to YPbPr
CVBS-1 Input
Switches the input to CVBS-1
CVBS-2 Input
Switches the input to CVBS-2
CVBS-3 Input
Switches the input to CVBS-3
KEY-UP ▲
CURSOR UP on Menu Control.
KEY-DOWN ▼
CURSOR DOWN on Menu Control.
KEY- MENU
Menu On/Off
KEY-ENTER
Enter Button
Aspect
Aspect On/Off
1:1 Scan On/Off
1:1 SCAN Function On/Off
H/V Delay On/Off
H/V Delay Function On/Off
TC Display On/Off
TC Display On/Off
ALM Display On/Off
Audio Level Meters Display On/Off
Freeze On/Off
Freeze Frame On/Off
Front Button LED On/Off
Front Button LED On/Off.
Tally Red On/Off
Tally Red LED On/Off
Tally Green On/Off
Tally Green LED On/Off
Backlight
Set the backlight intensity from 0 to 40. An LCD panel requires more than 30 minutes to be settled
to a new backlight value.
Front Button LED
Set front LEDs on/off status.
25
