BOOM TRIKES V1 AUTOMATIC - Wiring Diagrams - Legend

34
5.1 W IRING DIAGRAMS – L EGEND
Lights / brake lights
X4 Switch handlebars
S3 Switch fog light
BS Switch brake light
E1 Dipped beam, left
E2 Dipped beam, right
E3 Main beam, left
E4 Main beam, right
E5 L/h parking light inside headlamp
E6 R/h parking light inside headlamp
E7 Tail lamp, left
E8 Tail lamp, right
E9 Parking light, right, on wing
E10 Parking light, left, on wing
E11 Rear fog light
E12 Reverse light
E15 Instrument lights
E16 Number plate light
H7 Brake light, left
H8 Brake light, right
H9 Additonal brake light
H12 Main beam warning light
RS1 Tail light switch 1
RS2 Tail light switch 2
TK2 Touch sensitive switch throttle valve
SV Tail light switch 3
Engine
DKP Throttle valva – potenitometer
OS Oil pressure switch
LTS Engine speed / air temperature sensor
OTS TDC sensor
MTS Engine temperature sensor
ZS Ignition coil
M1 Electric starter
KSPG Fuel pump
KLS Radiator
LLS Connector neutral indicator
K1 Power supply relay, engine management
K4 Starter relay
K3 Fan relay
K2 Engine cutout relay
K6 Relay start lock-out
S11 Coolatnt temperature switch
DIAG Connector engine diagnostics
ESV Injeciton valve
SG Engine management
Power supply
S1 Ignition switch
X6 Alternator
B+ Battery
F1 Fuse, parking light, left
F2 Fuse, parking light, right
F3 Fuse, dipped beam, left
F4 Fuse, dipped beam, right
F5 Fuse, main beam, left
F6 Fuse, main beam, right
F7 Fuse, horn, engine cutout relay
F8 Fuse, brake light, tail light
F9 Fuse, instruments
F10 Fuse, hazard warning lights
F11 Fuse, engine management
F12 Fuse, engine management and power supply
F13 Additional fuse battery
F14 Back up light / Accessories (X38) = 10A
F15 Additional fuse 30A
F16 Additional fuse 30A
Connectors
X3 22-pin, to cockpit
X4 10-pin, to handlebars switchgear
X5 8-pin, to trailer coupling
X14 6-pin, to front lights, l/h
X15 6-pin, to rear lights, l/h
X16 6-pin, to front lights, r/h
X17 6-pin, to rear lights, r/h
X18 3-pin, to number plate / tail light
X21 3-pin, to tacho sensor
MP1 Earth connection to frame
B- Earth connection to battery
Warning lights / additional
instruments
B4 Sensor handbrake warning light
B5 Sensor brake fluid level
WT Water temperature gauge – additional instrument
H20 Brake fluid control light
H21 Alternator control light
H22 Oil pressure control light
U1 Reservoir gauge
U2 Water temperature gauge
U5 Tacho
Indicators / Hazard warning lights
/ Horn
S5 Hazard warning lights
K1 Indicator relay
H5 Indicator left at headlamp
H2 Indicator right at headlamp
H3 Indicator left rear
H4 Indicator right front
H10 Indicator warning light
H10/2 Indicator buzzer
H11 Indicator control lamp, trailer
H18 Horn
H18/2 Horn water temperature
K7 Relay Horn water temperature
