BOOM TRIKES V1 AUTOMATIC - Controls, Switchgear, Warning Lights and Instruments

7
2.1
C ONTROLS , SWITCHGEAR , WARNING LIGHTS AND INSTRUMENTS
Handlebar controls: (Fig. 1)
Functions:
1. Headlight flasher (at front)
2. Light switch
3. Parking light
4. Dipped beam
5. Main beam
6. Horn
7. Indicator
Fuel tank instruments / standard specifications
(Fig. 2):
1. Ignition switch
2. Water temperature gauge
(standard specifications only)
3. Rear fog light switch
4. Hazard warning light switch
5. Brake fluid warning light
3 4
Fig. 2
1
2
6
7
3
4
5
Fig. 1
1
5
2
