We cannot be held liable for accidents resulting from incorrect connection or which
could arise from the use of unearthed or poorly earthed appliance.
Electrical connection
•Theappliancemaybeinstalledandconnectedtothemainsonlybyaqualiedinstaller(electri-
cian) who is familiar with the applicable standards.
•Afterinstallationthelivepartsmustremainprotected.
•Therelevantconnectiondetailsareprovidedonthemodelplateandontheconnectionplateat
the bottom of the appliance.
•Theappliancemustbeisolatedfromthemainsbyamultipolecircuitbreaker.Intheopenposi-
tion(notconnected)thecontactgapmustbeatleast3mm.
•Theappliancemustbeisolatedfromthemainsbythenecessarydevices,suchascircuitbrea-
kers, fuses or contactors.
Caution!
Thisapplianceisdesignedforconnectiontoa230V~50-60Hzmainsnetwork.
Alwaysconnecttheearth.Followtheconnectiondiagram.Theconnectionboxisbelowthehob.
Openthelidbyputtingascrewdriverintothe2slotsbeforethe2arrows.
Connection of the hob
Usethegreen/yellowwireastheearth,thebluewireasneutralNandtheblackwireasphaseL.
Monophase 230V~1P+N (not for the Netherlands!)
Putthe1stbridgebetweenterminal1and2,the2ndbetween3and4.Attachtheearthtothe
terminate“earth”,theneutralNtoterminal3(or4),thePhaseLtooneoftheterminals1or2.
Biphase 400V~2P+N
Putabridgebetweenterminal3and4.Attachtheearthtotheterminate“earth”,theneutralN
toterminal3(or4),thePhaseL1totheterminals1andthePhaseL2totheterminal2.
Biphase 230V~2P+2N
AttachL1toterminal1,L2toterminal2,N1toterminal3,N2toterminal4andearthtoterminal
“earth”
Note! Push the wires right through and tighten the screws firmly.
Mains Connection Cable diameter Cable Protection calibre
230V~1P+N50Hz 1Phase+N 3x2,5mm² H05VV-F 25A*
   H05RR-F
400V~2P+N50Hz 2Phase+N 4x1,5mm² H05VV-F 16A*
   H05RR-F
230V~2P+2N50Hz 2Phase+2N 5x1,5mm² H05VV-F 16A*
   H05RR-F
*calculatedwiththesimultaneousfactorfollowingthestandardTN60335-2-6/1990
