18
4.4. Operation Test
All installation should be conducted or supervised by a qualified technician.
Charge the UPS for more than 8 hours after unpacking to ensure the batteries of
the UPS are fully charged before usage.
1. Make sure there is a proper grounding of the wall receptacle.
2. Verify if the voltage and frequency ratings match that of Utility, connect the
AC Input power cord to a verified grounded 3-wire receptacle.
3. Push on the Main switch on the front panel to start the UPS, the ventilation
fan should start indicating the UPS has been energized and performing self
test.
4. After 7~10 seconds, the start-up of UPS will be completed, then the "Utility"
LED and Inverter" LED will light up simultaneously.
5. Simulate a Mains failure by disconnecting the input power cord of the UPS to
see whether the UPS remains operation (DC Mode) when Utility is absent.
The "Utility" LED should extinguish and the alarm will sound continuously till
battery cut off. The UPS should continue to provide power supply at its
output terminals. To mute the audible alarm, please push the Test/Silence
Button on the front panel.
6. Re-connect the input power cord of the UPS to the utility receptacle. Push
the Main switch to Turn Off the UPS. Connect the power cord of your device
to the output receptacles of the UPS. Do not turn on your device at this time
7. Repeat Step 3 & 4. Turn on the switch of the device connected. Do not
perform critical application on your device at this time
8. Repeat step 5. The connected device should continue to operate without
interruption.
9. Your installation & operation tests are complete. You can turn on your device
and perform application on your device.
19
4.5. Storage Instruction
For extended storage in a controlled environment, store at -15 to +30 °C ,+5 to +86
°F, the batteries should be charged for 12 hours every 6 months by plugging the
UPS power cord into the wall receptacle. Repeat this step for every 3 months if the
storage environment ambient temperature is at +30 to +45 °C, +86 to +113 °F.
4.6. SNMP Slot
You may install the SNMP card into the SNMP slot on the rear panel of the UPS.
The UPS may be connected to a TCP/IP network management system via the
SNMP card. The SNMP slot kit is an optional feature of the UPS, so you shall
purchase the kit from your local distributor before installing the SNMP card.
The installation shall be executed by a qualified technician authorized by your local
distributor.
1. Insert the SNMP card into the SNMP slot.
2. Fasten the SNMP card properly.
3. Connect the network cable from the network device(ex. Hub) with SNMP
accessibility to the UPS and set the SNMP card to "configuration" mode and
configure the SNMP card.(Please refer to the user's manual of the SNMP Card
for configuration instruction.) Your hardware installation is now completed.
