English | 35
Bosch Power Tools 3 609 929 B34 | (3.4.08)
Changing Application Tools on the
Screw Head with External Square Drive
f When working with an application tool, pay
attention that the application tool is firmly
seated on the tool holder. When the applica-
tion tool is not firmly connected with the tool
holder, it can come loose again and not be
controlled.
An angled screw head with 1/4" square drive
(Article number 0 607 453 617) as well as one
with 3/8" square drive (Article number
0 607 453 620) are available for these industrial
cordless angle wrenches.
An angled screw head with 3/8" square drive
(Article number 0 607 451 618) is available for
these industrial cordless angle wrenches.
These industrial cordless angle wrenches are
supplied with a 3/8" sqaure drive angled screw
head.
Inserting
Press in the pin on the drive square of the tool
holder 2, e.g. using a small screwdriver, and
slide the tool bit 1 over the drive square. Pay at-
tention that the pin engages in the recess of the
tool bit.
Removing
Press in the pin in the recess of the tool bit 1
and pull the tool bit out of the tool holder 2.
Changing Application Tools on the
Screw Head with Internal Hexagon
(see figure F)
f When working with an application tool, pay
attention that the application tool is firmly
seated on the tool holder. When the applica-
tion tool is not firmly connected with the tool
holder, it can come loose again and not be
controlled.
An angled screw head with 1/4" internal hexa-
gon (Article number 0 607 453 618) is available
for these industrial cordless angle wrenches.
Inserting
Insert the tool bit 1 into the internal hex socket
of the tool holder 2 until it can be felt to engage.
Removing
Pull the tool bit 1 off of the tool holder 2 with
the aid of pliers, if necessary.
Operation
Use safety equipment. Always wear
eye protection. Safety equipment
such as dusk mask, non-skid safety
shoes, hard hat, or hearing protec-
tion used for appropriate conditions
will reduce personal injuries.
Starting Operation
When starting the power tool, you should first
select the direction of rotation with the rotation-
al direction switch 14 since the power tool
starts only when the rotational direction switch
14 is not in the middle position (switch-on lock).
Reversing the Rotational Direction
(see figure G)
Right rotation: For driving in screws, push the
rotational direction switch 14 left to the stop.
Left Rotation: For loosening or unscrewing
screws, push the rotational direction switch 14
right to the stop.
f Actuate the rotational direction switch 14
only when the machine is at a standstill.
ANGLE EXACT 2 | 3 | 6 | 7 | 7
–900 | 8 |
10–650 | 14–420 | 15
ANGLE EXACT 7–900 | 10–650 | 14–420 | 17 |
23 | 30
ANGLE EXACT 25
–250 | 30–380 | 40–280 |
50
–210
ANGLE EXACT 2 | 3 | 6 | 7 | 7
–900 | 8 |
10–650 | 14–420 | 15
OBJ_BUCH-412-001.book Page 35 Thursday, April 3, 2008 3:18 PM
