About this documentation 7/52
RE 91071-01-B/03.2015, A2FM/A2FE Series 70, Bosch Rexroth AG
Table 2: Hazard classes as defined in ANSI Z535.6
Warning sign, signal word Meaning
DANGER
Indicates a hazardous situation that, if not avoided, will
result in death or serious injury.
WARNING
Indicates a hazardous situation that, if not avoided, could
result in death or serious injury.
CAUTION
Indicates a hazardous situation that, if not avoided, could
result in minor or moderate injury.
NOTICE
Property damage: The product or the environment could be
damaged.
1.3.2 Symbols
The following symbols indicate information that is not directly relevant to safety but
increases understanding of the documentation.
Table 3: Meaning of the symbols
Symbol Meaning
If this information is not observed, the product cannot be used or operated
to its full potential.
▶
Single, independent step
1.
2.
3.
Numbered instruction:
The numbers indicate that the steps must be completed one after the other.
1.3.3 Designations
This documentation uses the following designations:
Table 4: Designations
Designation Meaning
A2FM Axial piston fixed motor in standard design, open and closed circuits
A2FE Axial piston fixed motor in plug-in design, open and closed circuits
Threaded plug Metal screw, pressure-resistant
Protection plug Made out of plastic, not pressure-resistant, only for transportation
As a generic term for the “axial piston fixed motor A2FM” and “axial piston plug-in
motor A2FE”, the designation “axial piston unit” will be used from now on.
