Bosch ADS 525X - General Information; Top View; Bottom View

1699502643 | REV. B | 05.2020
© Bosch Automotive Service Solutions Inc
ADS 525X
|
Quick Start Guide
|
3
|
en-US
General Information
Introduction
Connected
Generic OBDII
Repair-Source
10:22
QuickScan
Apps Shortcut
Settings
What’s New
Web Browser Coverage Guide Video Tutorials
Diagnostic Information Wiring Diagrams
i
i
Saved Reports
Main Menu
Diagnostics
1
2
3
4
8
4
5 6 7
11
8
109
1918
222120
24
23
25
17
141312 15
1. Camera
Front facing camera
2. Ambient Light Sensor
3. Vehicle Connection
Indicator
4. VCI Connection Manager
5. Power Button
6. Volume Up
7. Volume Down
8. Main Menu Functions
9. Recent apps button
10. Home Button
11. Back button
12. Future Use
13. Micro USB
14. Camera
Rear Facing Camera
15. Speaker
TOP VIEW
BOTTOM VIEW
