Preface
This manual describes how to install and mount the VG4 series AutoDome Modular Camera System. The manual
details the methods to mount the VG4 series to a wall, corner or mast; to a roof parapet or pipe; or in the ceiling.
The manual also includes information on cable and wire standards and information for connecting alarms and relays.
Audience
This manual is intended for qualified installation and service personnel who are familiar with the applicable national
and local electrical codes.
Document Conventions
Symbols
You may encounter these symbols within the document. Explanatory text accompanies each symbol, which provides
additional information detailing the operation or highlighting safety information.
Convention Meaning
Bold Denotes a part, item, or assembly.
Italic Denotes a reference to another paragraph, figure or table.
Underline
Used to emphasize a point.
courier Denotes the actual name of an object, the exact code that should be typed or a message returned
from a system.
i
NOTICE! Notices inform you of essential but non-critical information. Read these messages
carefully as any directions or instructions contained therein can help you avoid making
mistakes.
CAUTION! Cautionary messages provide critical information that help you reduce the chance
of losing data or damaging the system. Please heed these messages.
!
WARNING! Warnings highlight information, that if overlooked may cause damage to the
system or result in personal injury. Take warnings seriously.
DANGER! Danger messages denote the presence of electrical equipment that may cause
electric shock or electrocution. Take care when you see this symbol to avoid serious injury or
death.
