5.9 Working with lists
Detectors 2nd floor
Detector
4-1
Bypass
Un-
bypass
5-2
Detector
Office
2 3
1
5
4
4
Entrance hall
Detector
5-1
1 List 4 Scroll up / scroll down
2 List field 5 Function fields
3 Search mask
In many menus, elements are displayed in lists. The elements are sorted either by description
or address. Up to three different sorting criteria can be offered:
– By description: sorted by description in alphabetical order; address allocation also given.
– By number: sorted in ascending order by number (logical or physical address);
description also given.
– By number (no description shown): by number (logical or physical address) in ascending
order; the numbers are displayed in number blocks and the description is not given. This
list is only offered when detectors and logical zones are being selected.
Example:
To display a list of all existing detectors sorted by description in the Bypass submenu, select
the following in the start menu:
1. Bypass Block
2. Bypass
3. Detector
Three sorting criteria are offered for selection:
– By description
– By number
– By number (no description shown)
4 Select By description.
A list of all detectors is displayed, sorted in alphabetical order.
