Rober t Bosch GmbH
12 | BAT 490 | Configur ationen
5.1.2 Buffer/Backup mode parameters
! Incorrect parameter values (excessively high values)
may destroy the battery.
The "Buffer/Backup mode" parameter set displays the
following e. g.
Voltage 13,5V
Current 90A
Range: 11,0V-14,0V
Buffermode 12V
The following parameters can be selected in Buffer mode:
Battery Voltage Current
12 V 11 V – 14 V 3 A – 90 A
24 V 22 V – 28 V 3 A – 45 A
The following parameters can be selected in Backup mode:
Battery Voltage Current
12 V 10 V – 13 V 3 A – 10 A
24 V 20 V – 26 V 3 A – 10 A
1. Select the parameter with or .
2. Press .
? The next parameter is activated.
3. Select the parameter with
or .
4. Press .
5. Keep pressing until the configuration menu is
terminated.
6. Connect the battery and select "Buffer mode" or
"Backup mode".
"Buffer/Backup mode is implemented with the set
parameters.
5.2 Language
The "Language" menu is used to set the BAT 490 pro-
gram language.
1. Select the "Language" menu item.
2. Press
.
? The "Language" menu is displayed.
3. Select the language with
or .
4. Press .
? Language selected.
5. Keep pressing
until the "Language" menu is termi-
nated.
5.3 Contrast
The "Contrast" menu is used to set the contrast
of the LCD.
1. Select the "Contrast" menu item.
2. Press
.
? The "Contrast" menu is displayed.
3. Set the contrast with
or .
4. Press .
? Contrast set.
5. Keep pressing
until the "Contrast" menu is termi-
nated.
5.4 Software version
The "Software version" menu displays the current soft-
ware version of the BAT 490.
1. Select the "Software version" menu item.
2. Press
.
? The software version is displayed.
3. Keep pressing
until the "Software version" menu
is terminated.
5.5 Factory setting
The customer-specific parameters are deleted and
replaced by the factory parameters in the "Factory set-
ting" menu.
1. Select the "Factory setting" menu item.
2. Press
.
3. Press .
? Factory parameters set.
4. Keep pressing
until the "Factory setting" menu is
terminated.
