Robert Bosch GmbH
Maintenance | BAT 490 | 13 BAT 490 | | en
6. Maintenance
6.1 Faults
Problem Action to be taken
No BAT 490 function
after switch-on
(red LED does not light)
Pull the mains connector and
check the power supply and po-
wer cord.
Red LED flashes after connec-
ting the battery
Check the polarity at the batte-
ry. The red charging clip must
be connected to the positive
post (+) and the black charging
clip to the negative post (–) of
the battery.
Overload: Maximum current va-
lues reached for Buffer and
Backup mode.
The red LED stops flashing on-
ce the overload situation has
been rectified.
6.2 Replacement and wearing parts
Designation Order number
2 m power cord 1 684 423 085
Red/black charging cable set
(3 m; 10 mm
2
)
1 687 011 519
Red/black charging cable set
(5 m; 10 mm
2
)
1 687 011 520
<)
Wearing part
6.3 Cleaning
Only use a soft cloth and neutral detergents to clean
the housing and display of the BAT 490. Do not use ab-
rasive cleaning agents and coarse workshop cloths.
6.4 Disposal
This BAT 490 is subject to European guideli-
nes 2002/96/EG (WEEE).
Old electrical and electronic devices, including-
cables and accessories or batteries must be
disposed of separate to household waste.
¶
Please use the return and collection sys-
tems in place for disposal in your area.
¶
Damage to the environment and hazards to
personal health are prevented by properly
disposing of BAT 490.
7. Technical data
Property Value, Range
Charging current max. 90 A
Length of charging cable
*)
Length of charging cable (USA)
*)
3 m
9.8 ft
Charging cable cross-section 10 mm
2
Power input 1600 W
Weight 10,5 kg
Standard charging characteristic IUIaIaI
Expert-charger characteristic IUoU
Standard charging cut-off voltage
(temperature-regulated)
12 Volt
24 Volt
14 V – 14,4 V
28 V – 28,8 V
Backup mode 12 V
Backup mode 24 V
10 V – 13 V / 3 A – 10 A
20 V – 26 V / 3 A – 10 A
Buffer mode 12 V
Buffer mode 24 V
11 V – 14 V / 3 A – 90 A
22 V – 28 V / 3 A – 45 A
Funktions-Temperaturbereich 0 °C – 40 °C
Mains voltage/frequency (100 V) 100 V – 120 V, 50/60 Hz
Rated battery voltage 12 V / 24 V
Degree of protection (DIN 40050) IP 20
Safety class (DIN 40530) I
Dimensions (W x H x D)
Dimensions (W x H x D) (USA)
300 x 200 x 390 mm
11.8 x 7.9 x 15.4 inch
Workplace-related
noise emission value (Lpa)
< 70 dB(A)
Conducted interference level DIN 40839 Conducted
interference level I
*)
The charging cables are not to be modified.
