Bosch BCC100 User Guide

8
Attach BCC100 to the Wall Plate
Align the two clips on
the back of the
BCC100 into the
corresponding slots
on the top of the
wall plate.
4
Firmly press forward
until you hear a click to
secure the thermostat
into position.
1
2
PUSH
CLIPS
Switch on the power to the heating/cooling system at the
main switch box. If the thermostat does not power on,
remove the BCC100 from the wall and ensure the RH/RC
wire(s) and C-wire are correctly connected to both the
appliance and the thermostat.

Bosch BCC100 Specifications

General

Connectivity	Wi-Fi
Voice Control	Amazon Alexa, Google Assistant
Type	Smart Thermostat
Display	LCD
Compatibility	24V HVAC systems
Mobile App	Bosch Connected Control app
Scheduling	7-day
Power Source	Hardwired
