Bosch C1 - List of Parts; Technical Data

13 | english
04.2015 | C1 | Battery charger Automotive Aftermarket
List of parts
1 Charger
2 Terminals
3 Power cord with mains connector
4 Charging cable (red and black)
5 (+) Terminal (red)
6 (–) Terminal (black)
7 Standby / power indicator
8 Mode selection button
9 Totally discharged battery
10 Charge status
FULL
“ok” (lit)
Charge maintenance (flashing)
11 Charge status (Charging)
12 Mounting hook
Technical data
Primary
Rated
input voltage: 230 V / 50 Hz
Starting current: < 50 A
Rated input current: max. 0.6 A (rms value)
Power input: 60 W
Secondary
Rated output voltage: 12 V
Charging voltage: 14.7 V (± 0.25 V)
Charging current: 3.5 A (± 10 %)
Rated output current: 3.5 A
Ripple
1
: max. 150 mV
Backflow current
2
: < 5 mA (no AC input)
Degree of protection: IP 65 (dustproof, water-
tight)
Battery type: 12 V lead acid
battery (EFB, GEL, open
and VRLA)
Battery capacity: 12 V:5 Ah–120 Ah
Fuse (internal): 1.6 A
T1.6A
Noise level: < 50 dBA
Ambient
temperature: 0 to + 40 °C
Dimensions: 185 x 81 x 47 mm
(L x W x H)
