Bosch Camera - Choosing the Right Camera

04
This table summarizes the Bosch CCTV camera range.
Starting from your requirements or typical application
area, it is easy to select the most appropriate model.
Choosing the right Camera
FlexiDome I FlexiDome II FlexiDome
XT
Din
B/W Color B/W Color B/W Color B/W
Imager 1/4” 1/4” 1/4” 1/4” 1/4” 1/4” 1/3”
Horizontal Resolution 380 330 570 470 570 470 380
Sensitivity 50 IRE (Lux) 0.5 4.5 0.5 4.5 0.2 2 0.12
Lens types / connector Integral Integral Integral Integral Integral Integral
Lens wizard NA NA NA NA NA NA yes
Integral Lens
2.1, 3 or 6mm 2.1, 3 or 6mm 2.1, 3 or 6mm 2.1, 3 or 6mm 2.8 - 6mm 2.8 - 6mm NA
Signal-to-Noise >46dB >46dB >48dB >48dB >48dB >48dB 50dB
Dust/water protection IP43 IP43 IP43 IP43 IP66 IP66 NA
Impact protection NA NA NA NA ≥50 joules ≥50 joules NA
Supply Voltage 12-28VAC/DC 12-28VAC/DC 12-28VAC/DC 12-
85-265 VAC Mains. 85
Backlight Compensation On / Off On / Off On / Off On / Off On / Off On / Off On / O
Synchronisation LL/X-tal LL/X-tal LL/X-tal LL/X-tal LL/X-tal LL/X-tal LL / X-
Video Output 1.0 Vpp 1.0 Vpp 1.0 Vpp 1.0 Vpp 1.0 Vpp 1.0 Vpp 1.0 Vp
NightSense
EDR
Day/night IR switch
Video Motion Detection yes*
3
15 bit processing
AutoBlack yes
Cable compensation
3 operating modes
OSD menu yes
Remote set-up yes*
2
