8. Hardware Specifications
The following table lists the various hardware charac-
teristics of the CDR 900.
CDR 900 HARDWRE SPECIFICATIONS
HOST INTERFACE
Wired USB High Speed Client Port
(480 Mbps)
Ethernet 10/100 Mbps
Wireless 802.11b/g/n on USB Dongle
Bluetooth Version 2.0 EDR on
USB Dongle
PROCESSOR SYSTEM
Microprocessor Type I.MX6 Solor Processor
Clock Speed 800 MHz
RAM SDRAM : 512 Mbytes DDR3:
64M X 32
ROM NAND Flash: 256 Mbytes
Mass Storage Micro SD Card Slot – No
card installed (Optional from
4Gbyte to 128Gbyte)
USER INTERFACE
LED 4 LED’s - two LED’s are du-
al color
Audio Beeper (software frequency
controlled)
Keypad 3 momentary switches plus 3
back-lighting LED’s
Switch Recovery switch (for restora-
tion of fail-safe software)
POWER
Vehicle (12V) From vehicle battery via DLC
External (12V) - From CDR Power Supply
(P/N: 02002435)
- From vehicle battery via bat-
tery clips
- From 12V jump box
External USB power
Backup 15 seconds typical (5F Ultra-
Cap)
MECHANICAL CHARACTERISTICS
Size 1635mm x 115mm x 40mm
Weight 240 grams
Input Voltage 6VDC to 16VDC
Power Sources • 9 - 16 Volt vehicle power
• USB power
Operating temperature -20ºC to 70ºC using intelligent
staged temperature manage-
ment and shutdown
